$2,799.00
In Stock

Calculate Shipping



Express Shipping - $25.00
Auspost express
Standard Shipping - $15.00 (ETA: 5 days)
Cheapst shipping method

NOTE THIS IS A PRE-ORDER ITEM and is expected aroumd mid july


Please note this is without a payload release, or a camera, you will need to purchase these seperately





- In the Box -
x1
Aircraft
x1
Remote Controller
x2
Propellers(pair)
x1
Intelligent Battery
x1
Power Adapter
x1
Power Cable
x1
RC Barrel Power Cable
x1
Micro USB Cable
x1
Hex Screwdriver x2 Hex Screw
x1
Barometric Vent(extra)
x1
-Manuel -Certificate -Maintenance
x1
Case





Aircraft

Waterproof Rating:IP67

Drone Weight (include battery and propellers)2.18 kg

Axis Diameter:450 mm

Max Ascend Speed:4 m/s

Max Descend Speed:4 m/s

Max Flight Speed:22 m/s (ATTI)); 10 m/s (GPS)

Max Tilt Angle:12.5° (ATTI); 25° (ATTI fast)

Max Takeoff Altitude:120m (GPS) / ATTI - no limitation

Max Wind Speed Resistance:8 m/s (11-16knots)(F4); 14 m/s (F7) peak gust

Max Flight Time:30 mins (no wind & no load) (approx. 25 mins with GC3-S, approx.15 mins with load of 1.5kg)

Max Flight Distance:5.0 km

Max Payload Capacity:2.0 kg

Propellers:#1242 carbon fiber quick release propellers

Operating Frequency:5180 - 5875 MHz

Transmitter Power (EIRP):FCC/IC: ≤ 24 dBm CE/SRRC/MIC: ≤ 20 dBm

Working Temperature:-10℃ ~ 40℃

Satellite Positioning Systems:GPS/GLONASS

Hovering Precision:±0.5 m (vertical); ±0.5 m (horizontal)

Pass-through Serial Port:Connect to a third-party device and transfer the data of the third-party device to the remote control

UART:Allows for TTL serial port to TCP, support baud rate of 115200

Wi-Fi Hotspot:IP: 192.168.1.101:2222

Power Input:12V/2A | 5V/2A

Remote Control

Waterproof Rating:IP66

Operating Frequency:5180 - 5875 MHz

Transmitter Power (EIRP):FCC/IC: ≤ 24 dBm CE/SRRC/MIC: ≤ 20 dBm

Real-time Video Transmission:720P@30fps

Latency:200 ms (It depends on the actual shooting environment and mobile devices)

Battery:2S 3600mAh

Working Time:7 hours

Working Current/Voltage:0.3A/7.4V

Ethernet Port:IP: 192.168.2.220:2222

Wi-Fi Hotspot:IP: 192.168.2.220: 2020; Default password: 12345678

Mobile Device Mount:Suitable for any size phones; Tablets require a larger mount (sold separately)

Screen:2.68 inch, 128x64

Working Temperature:-10℃ - 40℃

Remote Charging time:3 hours

Power Input:5V/2A

Intelligent Battery

Nominal Capacity:6600mAh

Voltage:14.8V

Type:Intelligent 4S LiPo

Watt Hours:97.68 Wh

Size:153.6*82.4*48.3mm

Weight:735 g (±5 g)

Working Temperature:-10℃ - 40℃

Charging Time:1.5 hour

Max Charging Power:84 W

Charger

Input:100 – 240V, 50/60Hz

Output:16.8V@Dynamic Current / 5V@1.5A

Rated Power:84.5 W

Mobile Device connection

Operation Frequency:5180 - 5875 MHz

Max Transmission Distance:10 m (Unobstructed, free of interference)

APP

Mobile App Name:NaviFly

Live View Quality:720p@30fps

Latency:< 250 ms (depending on environmental conditions and mobile devices)

3-Axis Gimbal Camera (GC3-S)

Waterproof:IP67

Axis:3 axis (pitch, roll, yaw)

Pitching Angle:-90° to 0°

Maximum Control Speed:Pitch 60°/s

Weight:Approx. 310g

Size:113*92*110mm

Image Sensor:1/2.3" 12M SONY CMOS

Lens:F4.53mm f/2.65, FOV: 92.6°

ISO range:100 - 3200

Shutter Speed:16 - 1/16000 s

Photo Resolution:4:3/16:9 12M pixel

Photo Shooting Mode:A single shot

Burst Photo:3/5/10 pcs

Interval Photo:1/3/5/10s

Video Resolution:4K: 3840*2160/30P | 2.7K: 2704*1520/60P | FHD: 1920*1080 30/60/120p | HD: 1280*720/240p

Max Video Stream:64 mbps

Photo Format:JPEG / DNG

Video Format:MP4, MOV

Support Memory Card:Micro-SD card with a maximum capacity of 128GB, write speed ≥15 MB/s, supports Class 10 or above & UHS-1 rating

Working temperature:-10℃ to 40℃

1-Axis Gimbal Camera (GC1)

Waterproof:IP67

Axis:1 axis (pitch)

Pitch angle:-90° to 0°

Maximum control speed:Pitch 60°/s

Weight:Approx. 145g

Size:71*55*65mm

Image Sensor:1/2.3" 12M SONY CMOS

Lens:F4.53mm f/2.65, FOV: 92.6°

ISO Range:100 - 3200

Shutter Speed:16 - 1/16000 s

Photo Resolution:4:3/16:9 12M pixel

Burst Photo:3/5/10 pcs

Interval Photo:1/3/5/10s

Video Resolution:4K: 3840*2160/30P | 2.7K: 2704*1520/60P | FHD: 1920*1080 30/60/120P | HD: 1280*720/240P

Max Video Stream:64 Mbps

Photo Format:JPEG / DNG

Video Format:MP4 / MOV

Support Memory Card:Micro SD CARDS with a maximum capacity of 128GB, write speed ≥60 MB/s, supports Class 10 or above & UHS-1 rating

Working Temperature:-10℃ to 40℃

2-Axis Low-Light Gimbal Camera (GC2-S)

Waterproof:IP67

Weight:Approx.220g

Size:113*92*80mm

Image Sensor:1/2" 2M Starlight CMOS

Lens:FOV: 66°

Burst Photo:3/5/10pcs

Interval Photo:1/3/5/10s

Video Resolution:FHD: 1920*1080 30/60P | HD: 1280*720 120/60P

Max Video Stream:64 Mbps

Photo Format:JPEG

Video Format:MP4 / MOV

Support Memory Card:Micro SD CARDS with a maximum capacity of 128GB, write speed ≥65 MB/s, supports Class 10 or above & UHS-1 rating

Working temperature:-10℃ to 40℃

Payload Release (PL1-S)

Waterproof Rating:IP67

Weight:96 g

Size:59*38*50mm

Max. loading weight:2 kg





(17564)
